• Trailer Spindles

    Trailer Spindles

    Trailer spindles serve as part of the trailer axle, and the hot-forged blank provides high-precision machining and strong mechanical performance.

    • Application and Features

      Production process: hot forging – machining – hole drilling – oil dipping – inspection – packing


      Suitable for use with almost all axle brands, including Dexter, Rockwell American, and Lippert.

      Axle capacity is equal to 2 times the spindle’s rated capacity.

      Also suitable for building custom axles.

      High tensile strength steel with precisely machined components.

      Grease Zerk for easy lubrication.

      Includes required components: washer, spindle nut, and cotter pin.

      1-year limited warranty.

      Inquiry Now


      Product Parameters


      DESCRIPTION

      PART NO.

      SP-HF-IF-84L

      SP-HF-IF-8455

      SP-HF-IFB-42L-213

      SP-HF-IFB-42L-225

      REF NO.

      SP126288

      SP-HF-IF-8455

      SP-HF-IFB-42L-213

      SP124551

      CAPACITY

      1750 LBS

      1750 LBS

      3500 LBS

      3500 LBS

      UNIT WT.

      3.29 LBS

      3.97 LBS

      7.31 LBS

      7.31 LBS

      DIMENSIONS

      A

      1.95"

      2.55"

      2.45"

      2.45"

      B

      3.00"

      3.00"

      3.25"

      3.25"

      C

      6.35"

      6.35"

      8.25"

      8.25"

      D

      1.72"

      1.72"

      2.13"

      2.25"

      E

      1.376"

      1.376"

      1.749"

      1.749"

      F

      1.062"

      1.062"

      1.249"

      1.249"

      H

      2.45"

      3.00"

      3.00"

      3.00"

      I

      5.36"

      5.46"

      7.25"

      7.25"

      APPLICATION

      Axle Tube

      2-3/8"

      2-3/8"

      3"

      3"

      Flange

      4 bolt 10"

      4 bolt 10"

      5 bolt 12"

      5 bolt 12"


    ...
    More details
  • Plastic Fender

    Plastic Fender

    Trailer fenders help protect cargo from mud, water, rocks, and other debris thrown up by the wheels while driving. They also shield the trailer’s structural components from corrosion and mechanical damage, supporting longer service life and better overall technical condition.

    • Product Information

      Our single and double mudguards are made from high-quality polypropylene (PP), delivering exceptional durability and full recyclability. They are extremely easy to install. The mudguards are designed for 13–16 inch wheels.

      Our mudguards are CE certified, confirming compliance with European quality and safety standards.


      We also offer steel fenders made from high-quality galvanized steel sheets. They are suitable for even harsher road and operating conditions and are commonly used on boat trailers. Compared with plastic fenders, they provide stronger corrosion resistance and increased durability, earning the trust and preference of customers.

      Inquiry Now


      Product Parameters


      Series Article No Size Material Unit W.T. / kg Colour Pallet Size / m Pcs / Pallet
      13" Fender HM05026 660*210*325mm PP/ABS 1.1 Black/Grey/White 2.2*1*1.7 200
      HM05029 590*180*160mm PP 0.6 Black/Grey/White 2.2*1*1.6 300
      14" Fender HM05027 770*215*325mm PP 1.1 Black/Grey/White 2.2*1*1.7 200
      15" Fender HM05083 935*240*300mm PP/Steel 2 Black/Grey/White 2.2*1*1.9 200
      16" Fender
      13" Double wheel Fender HM05028 1660*230*360mm PP 3.45 Black/Grey/White 2.2*1*1.7 100
      14" Double wheel Fender


    ...
    More details
  • Trailer Light

    Trailer Light

    Trailer plug and socket for reliable electrical connections on trailers.

    • Product Parameters


      Series Article No Description Capacity Unit W.t./kg Pcs/
      Package
      Carton Size/mm Package
      Lamp KTC022F-S Bulb lamp #KTC022F-S 7Pin 12V Emark 0.17 40 590*260*220 Each item packed in a plastic bag and box; then 40 pcs per carton.
      JH101 Bulb lamp #JH101 7Pin 12V Emark 0.08 100 530*530*230 Each item packed in a plastic bag and box; then 100 pcs per carton.
      JH120 LED lamp #JH120 7Pin 12V Emark 0.16 100 550*480*220 Each item packed in a plastic bag and box; then 100 pcs per carton.



    ...
    More details
  • Trailer Spindles

    Trailer Spindles

    Trailer spindles serve as part of the trailer axle, and the hot-forged blank provides high-precision machining and strong mechanical performance.

    • Application and Features

      Production process: hot forging – machining – hole drilling – oil dipping – inspection – packing


      Suitable for use with almost all axle brands, including Dexter, Rockwell American, and Lippert.

      Axle capacity is equal to 2 times the spindle’s rated capacity.

      Also suitable for building custom axles.

      High tensile strength steel with precisely machined components.

      Grease Zerk for easy lubrication.

      Includes required components: washer, spindle nut, and cotter pin.

      1-year limited warranty.

      Inquiry Now


      Product Parameters


      DESCRIPTION

      PART NO.

      SP-HF-IF-84L

      SP-HF-IF-8455

      SP-HF-IFB-42L-213

      SP-HF-IFB-42L-225

      REF NO.

      SP126288

      SP-HF-IF-8455

      SP-HF-IFB-42L-213

      SP124551

      CAPACITY

      1750 LBS

      1750 LBS

      3500 LBS

      3500 LBS

      UNIT WT.

      3.29 LBS

      3.97 LBS

      7.31 LBS

      7.31 LBS

      DIMENSIONS

      A

      1.95"

      2.55"

      2.45"

      2.45"

      B

      3.00"

      3.00"

      3.25"

      3.25"

      C

      6.35"

      6.35"

      8.25"

      8.25"

      D

      1.72"

      1.72"

      2.13"

      2.25"

      E

      1.376"

      1.376"

      1.749"

      1.749"

      F

      1.062"

      1.062"

      1.249"

      1.249"

      H

      2.45"

      3.00"

      3.00"

      3.00"

      I

      5.36"

      5.46"

      7.25"

      7.25"

      APPLICATION

      Axle Tube

      2-3/8"

      2-3/8"

      3"

      3"

      Flange

      4 bolt 10"

      4 bolt 10"

      5 bolt 12"

      5 bolt 12"


    ...
    More details
  • Plastic Fender

    Plastic Fender

    Trailer fenders help protect cargo from mud, water, rocks, and other debris thrown up by the wheels while driving. They also shield the trailer’s structural components from corrosion and mechanical damage, supporting longer service life and better overall technical condition.

    • Product Information

      Our single and double mudguards are made from high-quality polypropylene (PP), delivering exceptional durability and full recyclability. They are extremely easy to install. The mudguards are designed for 13–16 inch wheels.

      Our mudguards are CE certified, confirming compliance with European quality and safety standards.


      We also offer steel fenders made from high-quality galvanized steel sheets. They are suitable for even harsher road and operating conditions and are commonly used on boat trailers. Compared with plastic fenders, they provide stronger corrosion resistance and increased durability, earning the trust and preference of customers.

      Inquiry Now


      Product Parameters


      Series Article No Size Material Unit W.T. / kg Colour Pallet Size / m Pcs / Pallet
      13" Fender HM05026 660*210*325mm PP/ABS 1.1 Black/Grey/White 2.2*1*1.7 200
      HM05029 590*180*160mm PP 0.6 Black/Grey/White 2.2*1*1.6 300
      14" Fender HM05027 770*215*325mm PP 1.1 Black/Grey/White 2.2*1*1.7 200
      15" Fender HM05083 935*240*300mm PP/Steel 2 Black/Grey/White 2.2*1*1.9 200
      16" Fender
      13" Double wheel Fender HM05028 1660*230*360mm PP 3.45 Black/Grey/White 2.2*1*1.7 100
      14" Double wheel Fender


    ...
    More details
  • Trailer Light

    Trailer Light

    Trailer plug and socket for reliable electrical connections on trailers.

    • Product Parameters


      Series Article No Description Capacity Unit W.t./kg Pcs/
      Package
      Carton Size/mm Package
      Lamp KTC022F-S Bulb lamp #KTC022F-S 7Pin 12V Emark 0.17 40 590*260*220 Each item packed in a plastic bag and box; then 40 pcs per carton.
      JH101 Bulb lamp #JH101 7Pin 12V Emark 0.08 100 530*530*230 Each item packed in a plastic bag and box; then 100 pcs per carton.
      JH120 LED lamp #JH120 7Pin 12V Emark 0.16 100 550*480*220 Each item packed in a plastic bag and box; then 100 pcs per carton.



    ...
    More details
  • Trailer Plug & Socket

    Trailer Plug & Socket

    This 7-pin trailer plug is a universal accessory that fits all trailer types, including semi-trailers and tow trucks.

    • Product Information

      This 7-pin plug is available in two casing materials:

      A. A robust metal housing with a 12 V connector and metal pins, additionally galvanized to help prevent rust.

      B. A highly durable PVC housing, designed to be resistant to damage.

      It features a 12 V plug and rust-protected metal pins. Installation is straightforward, and it ensures a stable connection between the trailer’s electrical system and the vehicle—helping to maintain uninterrupted operation of all trailer lights while driving.

      Inquiry Now


      Product Information

      Our 7-PIN, 12 V trailer towbar socket is an essential component for establishing electrical connections between a vehicle and a trailer. The socket operates at 12 V and is compatible with most European passenger cars and vans.

      With 7 pins, the socket provides full functionality for all standard trailer lighting requirements, including brake lights, turn signals, and position lights. It also supports additional functions such as powering the trailer’s interior lighting and connecting to the trailer braking system.

      The socket housing combines metal and PVC components, matching the plug’s design. The socket is easy to install, and its universal design enables convenient mounting on various types of towbar applications. It is an ideal solution for customers who require a reliable and effective electrical connection when towing trailers.

      Inquiry Now


      Product Parameters


      SeriesArticle NoDescriptionCapacityUnit W.t./kgPcs/
      Package
      Carton Size/mmPackage
      ConnectorKTC004FTrailer Metal Case Plug-7Pin 12V7Pin 12V CE0.08100440*215*205Each packed in a plastic bag and box, then 100 pcs in a carton
      JH003-ATrailer Plastic Plug-7Pin 12V7Pin 12V CE0.08100440*215*205Each packed in a plastic bag and box, then 100 pcs in a carton
      KTC001F-DTrailer Metal Case Round Socket-7Pin 12V Elastic7Pin 12V CE0.09100370*310*280Each packed in a plastic bag and box, then 100 pcs in a carton
      JH001-DTrailer Plastic Round Socket-7Pin 12V Elastic7Pin 12V CE0.09100370*310*280Each packed in a plastic bag and box, then 100 pcs in a carton



    ...
More details
  • Hitch Ball and Mount

    Hitch Ball and Mount

    Trailer hitch balls from Hebei Minmetals are key components of a vehicle’s towing system, providing the connection point between the vehicle and the trailer. Typically made from durable steel or chrome-plated steel, these spherical metal hitch balls are designed to withstand significant stress and weight.

    • Product Information

      The diameter of the trailer hitch ball is a key factor and should be selected according to towing requirements. Common sizes include [Reference values] 1-7/8 inches, 2 inches, and 2-5/16 inches. Choose the correct size based on the trailer’s coupler/connection to ensure a secure, proper fit. Correct sizing is essential for safe towing, because an incorrectly sized hitch ball can lead to trailer sway, separation, or other hazardous conditions on the road.

      Inquiry Now


      Product Information

      Installation of a trailer hitch ball involves mounting it to a hitch receiver attached to the vehicle’s chassis. The hitch ball is secured using a threaded shank and a nut, and is often fitted with a cotter pin to help prevent the nut from loosening during travel.

      Inquiry Now


      Product Information

      Trailer hitch balls are also rated for specific load capacities. For example, a [Reference value] 1-7/8-inch hitch ball may have a lower weight capacity than a [Reference value] 2-5/16-inch one. It is essential to know the trailer weight and its load and to select a hitch ball with an appropriate rating. This supports safe towing performance while helping to extend the service life of the hitch ball and the overall towing system. Regularly inspect the hitch ball for signs of wear, rust, or damage. If any defects are found, replace the hitch ball promptly to maintain safe towing conditions.

      Inquiry Now



    ...
    More details
  • Trailer Locks, Hinges & Latches Door Hardware for Small Utility Trailers, Caravans & Enclosed Trailers

    Trailer Locks, Hinges & Latches Door Hardware for Small Utility Trailers, Caravans & Enclosed Trailers

    High-quality cam locks, T-hinges, strap hinges, drop latches, over-center latches, and more, designed for durable, secure operation in industrial applications. Suitable for use on equipment where reliable hardware performance and locking stability are required.

    • Product Overview

      We manufacture a complete range of locking and hinging hardware specially designed for small to medium trailers, including utility trailers, boat trailers, enclosed cargo trailers, and caravans.

      Our product portfolio includes a variety of door hinges, slam latches, cam locks, paddle latches, hasps, and brackets. All products are manufactured from high-strength steel with excellent corrosion resistance, making them suitable for outdoor use and harsh road conditions.

      Inquiry Now


      Our Main Product Range

      Door Hinges

      T-Hinges, Strap Hinges, Butt Hinges, Continuous (Piano) Hinges, Weld-on Hinges

      Locks & Latches

      Cam Locks, Over-Center Latches, Paddle Latches, Slam Latches, Drop Latches

      Locking Mechanisms

      Bar Locks, Deadbolt Locks, Hasps & Staples, Security Chains

      Brackets & Accessories

      Mounting Brackets, Corner Brackets, Handle Assemblies

      Inquiry Now


      Key Features & Advantages

      Heavy-Duty Construction

      High-tensile steel with reinforced design for reliable performance under vibration and load over time.

      Excellent Corrosion Resistance

      Zinc-plated, powder-coated, or stainless steel options for enhanced weather protection.

      Wide Application

      Ideal for rear doors, side doors, ramps, toolboxes, and compartment lids on small trailers.

      Strong Customization Capability

      We support full custom manufacturing based on drawings, samples, or special requirements.

      Inquiry Now


      Our Manufacturing & Customization Capabilities

      We are a professional trailer hardware manufacturer with strong processing capabilities. In addition to standard products, we excel in delivering custom solutions:

      Custom dimensions, shapes, and load requirements

      Reverse engineering and sample duplication

      Different materials: Carbon steel, Stainless steel, Aluminum alloy

      Various surface treatments: Zinc plating, Powder coating, Electrophoresis, Painting

      Private labeling and OEM/ODM services

      Small-batch trial orders are welcome

      Whether you need a modified standard part or a completely new design, our engineering team can deliver high-precision products with short lead times.

      Inquiry Now


      Quality Assurance

      All products undergo strict quality control, including:

      Material composition and strength testing

      Load and fatigue testing

      Corrosion resistance (salt spray) testing

      Locking mechanism durability cycling

      100% visual inspection prior to shipment

      Inquiry Now



    ...
    More details
  • Boat Trailer Rollers

    Boat Trailer Rollers

    Boat trailer rollers are used to launch and retrieve boats, providing a smooth, stable surface as the boat is pulled onto or off the trailer. Made from durable materials such as high-quality rubber or plastic, they help the boat glide safely and securely.

    • Product Information

      The rollers are strategically positioned along the trailer frame. Their round profile allows the boat to roll with minimal friction, helping to reduce the effort required to move the boat and minimizing the risk of damage to the hull. A range of roller sizes and types is available to suit different boat dimensions and weights. For heavier boats, larger and more robust rollers are typically selected to ensure the load is supported effectively.


      Boat trailer rollers also support safe and stable boating operations. By providing correct support and guidance, they help keep the boat centered on the trailer, reducing the likelihood of the boat shifting or becoming unstable during transport. Regular inspection and maintenance are essential. This includes checking for signs of wear, cracks, or other damage that may affect roller performance. If any issues are identified, the rollers should be replaced promptly to maintain smooth and safe operation of the boat trailer.

      Inquiry Now


      Product Parameters


      Series Article No Description (mm) Material Unit Wt. (kg) Colour Pcs/Package Pallet Size/m Package
      Boat Rollers TCOM-1 L=95; D=87; D1=54; d=φ13 PVC 0.44 Yellow 100 0.4*0.4*0.4 Each packed in plastic bag, then 100 pcs in carton
      Boat Rollers TCOM-2 L=190; D1=85; D2=75; D3=60; d=φ21 Rubber 1.15 Black 40 0.4*0.4*0.4 Each packed in plastic bag, then 40 pcs in carton
      Boat Rollers 360 713 L=199; L1=32; D=88; D1=60; d=φ22 Rubber 1.16 Black 40 0.4*0.4*0.4 Each packed in plastic bag, then 40 pcs in carton
      Boat Rollers 360 715 L=197; D=69; D1=59; d=φ17 Rubber 1.35 Black 40 0.4*0.4*0.4 Each packed in plastic bag, then 40 pcs in carton
      Boat Rollers 360 716 L=197; D=69; D1=59; d=φ21.5 Rubber 0.96 Black 40 0.4*0.4*0.4 Each packed in plastic bag, then 40 pcs in carton
      Boat Rollers TCOM-VBPVC L=108; L1=73; H=86; H1=50; W=71; d=φ12.5; dH=20 PVC 0.3 Yellow 100 0.4*0.4*0.4 Each packed in plastic bag, then 100 pcs in carton
      Boat Rollers TCOM-VBPU PU 0.29 Blue 100 0.4*0.4*0.4 Each packed in plastic bag, then 100 pcs in carton
      Boat Rollers 360 719 L=77; D=121; D1=97; D2=32; d=φ18 Rubber 0.68 Black 75 0.65*0.38*0.38 Each packed in plastic bag, then 75 pcs in carton
      Boat Rollers 360 722 L=135; L1=90; H=90; H1=65; W=75; d=φ14; dH=20 Rubber 0.63 Black 50 0.4*0.4*0.4 Each packed in plastic bag, then 50 pcs in carton
      Boat Rollers 1 224 432 L=76; D=71; D1=35; d=φ13.5 PU 0.19 Orange 100 0.4*0.4*0.4 Each packed in plastic bag, then 100 pcs in carton
      Boat Rollers 1 224 429 L=150; L1=77; H=75; H1=36; W=71; d=φ12.5; dH=17.5 PU 0.23 Orange 100 0.4*0.4*0.4 Each packed in plastic bag, then 100 pcs in carton
      Boat Rollers 1 224 434 L=27; L1=13; D=105; D1=80; d=φ13 PU 0.45 Orange 150 0.38*0.38*0.38 Each packed in plastic bag, then 150 pcs in carton
      Boat Rollers 6X1064.018 L=194; D=90; D1=61; d=φ17 PVC 1.24 Blue 40 0.4*0.4*0.4 Each packed in plastic bag, then 40 pcs in carton
      Boat Rollers 6X1064.004 L=194; D=90; D1=61; d=φ17 PVC 1.28 Yellow 40 0.4*0.4*0.4 Each packed in plastic bag, then 40 pcs in carton
      Boat Rollers 6X1064.019 L=259; D=93; D1=61; d=φ17 PVC 1.52 Blue 30 0.4*0.4*0.4 Each packed in plastic bag, then 30 pcs in carton
      Boat Rollers 6X1064.020 L=259; D=93; D1=61; d=φ17 PVC 1.98 Blue 25 0.4*0.4*0.4 Each packed in plastic bag, then 25 pcs in carton
      Boat Rollers 6X1067.015 L=75; D=128; d=φ22 PVC 0.512 Blue 75 0.65*0.38*0.38 Each packed in plastic bag, then 75 pcs in carton


    ...
    More details
  • 48mm and 60 mm Jockey Wheel for Car Trailer Support Wheel

    48mm and 60 mm Jockey Wheel for Car Trailer Support Wheel

    Outer tube options: Ø48 mm or Ø60 mm. Supplied with an 8” or 10” rubber wheel for use on carts and handling equipment.

    • Product Overview

      Our Jockey Wheel is an ideal support wheel solution, specifically engineered for light- and medium-duty trailers. It features a robust 48 mm or 60 mm outer tube and a 200–260 mm solid rubber tire, delivering excellent stability and maneuverability when parking or positioning your trailer.

      Available with standard red/black handles and in galvanized or HDG finishes, with multiple load ratings. We provide OEM-quality products and support full customization based on customer drawings or samples.

      Inquiry Now


      Key Features & Benefits

      Robust Tube

      High-strength steel outer tube ensures stability and a long service life under load.

      Smooth Rolling Wheel

      The solid rubber tire provides good ground clearance and low rolling resistance.

      Easy Height Adjustment

      Telescopic design with multiple height positions and a secure locking mechanism. A clamp for the jockey wheel is also available.

      OEM & Custom Service

      Standard models are available. Full customization includes length, wheel type, load capacity, and branding.

      Inquiry Now


      Technical Specifications


      Parameter

      Details

      Model

      48 mm / 60 mm Jockey Wheel

      Outer Tube Diameter

      48 / 60 mm

      Wheel Diameter

      200–260 mm

      Wheel Width

      50 mm+

      Tire Type

      Solid Rubber (pneumatic optional)

      Static Load Capacity

      150 kg – 500 kg (model dependent) (reference range)

      Material

      High-strength steel tube + durable rubber tire

      Height Adjustment

      Telescopic with multiple positions

      Surface Treatment

      Zinc and HDG

      Installation

      Compatible with standard jockey wheel clamps

      Applications

      Small utility trailers

      Caravan & camping trailers

      Boat trailers

      Horse boxes

      Agricultural equipment

      Light commercial trailers

      Ideal for: Trailers with tongue weight up to 400 kg. Suitable for small to medium-sized towing vehicles.

      Inquiry Now


      Customization Service

      In addition to standard 48 mm jockey wheels, we offer professional customization:

      Different lengths and height ranges

      Pneumatic or solid rubber wheels

      Custom load capacities and colors

      Reverse engineering from samples

      Private labeling and OEM branding

      Inquiry Now


      Quality Assurance

      Each jockey wheel undergoes rigorous safety and durability checks:

      Static and dynamic load testing

      Height adjustment mechanism durability

      Corrosion resistance (salt spray test)

      Wheel rolling and wear testing

      Inquiry Now



    ...
    More details
  • View all products
    HEMCO manufacturing workshop

    The Group - Hebei Minmetals Co Ltd, registered with capital of 60M RMB, has a history of over 35 years which derives from state owned company in 2004.

    Under the group, there's different business sectors as Fence, Lawn & Garden, Building Material, Auto Parts, Hardware, Warehousing, and Home Organization.

    Hemco covers 70,000 sqm workshop, invested 3 leaf spring production lines, 1 machining line, 9 cold forming lines, 2 bending machines, 4 lasers, 4 plastic injection lines.

    More details

    Production Lines

    We offer professional leaf spring and car trailer parts produced by the equipment of our company, which allows you to get products exactly according to your size.

    Our Partners

    For over 35 years, HEMCO along with Hebei Minmetals has been building relationships and projects that last. We utilize environment friendly and high-automatic solutions in the products we manufacture.

    What Types Of Leaf Springs Do You Manufacture?

    We produce a full range of high-quality leaf springs, including light duty trailer leaf springs, medium duty LCV leaf springs, heavy duty truck leaf springs, and Z-type parabolic leaf springs. All are made from premium spring steel with excellent load capacity and durability.

    Do You Offer Custom Leaf Springs?

    Yes! We support full custom leaf springs manufacturing. Whether you provide drawings, samples, or specific load requirements, our team can create OEM-quality custom made leaf springs for your unique trailer or vehicle needs.

    What Is A Jockey Wheel And Which Size Should I Choose?

    A jockey wheel (also called trailer support wheel) helps maneuver your trailer when detached. We offer 48mm jockey wheels and 60mm jockey wheels with solid rubber or pneumatic tires, suitable for small utility trailers, caravans, and boat trailers.

    What Is The Difference Between Coupling Head And Hitch Ball?

    A coupling head (tow hitch coupler) connects to your vehicle’s hitch ball. We supply durable 40-60mm coupling heads and various sizes of trailer hitch balls for safe and secure towing.

    Are Your Trailer Parts Suitable For Heavy Duty Applications?

    Absolutely. Our heavy duty leaf springs and reinforced trailer accessories (including locks, hinges, and latches) are designed for commercial trucks, agricultural machinery, and heavy trailers, with strict quality testing.

    Do You Provide Oem And Wholesale Services?

    Yes. We are a professional manufacturer offering OEM leaf springs and trailer parts. We welcome wholesale orders and long-term business partnerships with competitive pricing and reliable delivery.

    More details

    Request a Quote
